| Specifications: | |
| Model Number | DHIPQ50/28RG-50M-M-I |
| Image Sensor | 1/2.7”5 Megapixel progressive CMOS |
| Effective Pixels | 2592(H) X 1944(V) |
| Scanning System | Progressive |
| Electronic Shutter Speed | Auto/Manual, 1/3 s~ 1/100000s |
| Min. Illumination | 0.005 Lux@F1.6 |
| S/N Ratio | More than 50dB |
| Max. IR LEDs Length | Distance up to 50m |
| IR On/Off Control | Auto/ Manual |
| IR LEDs | 2 |
| Lens | |
| Lens Type | Fixed |
| Mount Type | M12 |
| Focal Length | 2.8mm |
| Max. Aperture | F1.6 |
| Field of View | Horizontal: 98°; vertical: 72°; diagonal: 130° |
| Iris Type | Fixed aperture |
| Close Focus Distance | 0.9 m |
| DORI Distance | Detect: 56 m
Observe: 22.4 m
Recognize: 11.2 m
Identify: 5.6 m |
| Intelligence | |
| Perimeter Protection | Tripwire; intrusion (Recognition of human and vehicle) |
| Intelligent Search | Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos |
| Video | |
| Compression | H.265; H.264; H.264H; H.264B; MJPEG |
| Smart Codec | Yes |
| Streaming Capability | 3 Streams |
| Resolution | 5M (2592 × 1944); 4M (2688 × 1520); 3M (2304 × 1296);
1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720);
D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240) |
| Frame Rate-Main Stream | (2592 × 1944@1–20 fps); (2688 × 1520@1–25/30 fps) |
| Frame Rate-Sub Stream | (704 × 576@1–25/30 fps) |
| Frame Rate-Third Stream | (1280 × 720@1–25/30 fps) |
| Bit Rate Control | CBR/VBR |
| Bit Rate | H.264: 3 Kbps–8192 Kbps
H.265: 3 Kbps–8192 Kbps |
| Day/Night | Auto(ICR) / Color / B/W |
| BLC | Yes |
| HLC | Yes |
| WDR | 120dB |
| White Balance | Auto/ Natural/ Street Lamp/ Outdoor /Manual / Regional custom |
| Gain Control | Auto/ Manual |
| Noise Reduction | 3D DNR |
| Motion Detection | Off / On (4 Areas, Rectangle) |
| Region of Interest | Yes (4 Areas) |
| Smart IR | Yes |
| Image Rotation | 0°/ 90°/ 180°/ 270° (Support 90°/270° with 1920 × 1080 resolution.) |
| Mirror | Yes |
| Privacy Masking | 4 Areas |
| Audio | |
| Built-in MIC | Yes |
| Audio Compression | G.711a/ G.711Mu/ AAC/ G.726 |
| Network | |
| Ethernet | RJ-45 (10/100Base-T) |
| Protocol | IPv4; IPv6; HTTP; HTTPS; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP;
DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; PPPoE;
802.1x; SNMP |
| Interoperability | ONVIF (Profile S/ Profile G); CGI; P2P; Milestone; Genetec |
| Scene Self-adaptation | Yes |
| Max. User Accessr | 10 Users |
| Edge Storage | FTP; SFTP; Micro SD Card (support max. 256 G); Cloud; NAS |
| Web Viewer | IE: IE8, IE9, IE11, Chrome, Firefox |
| Management Software | SPRO CSS |
| Smart Phone | iPhone, iPad & Android |
| General | |
| Power Supply | DC12V, POE |
| Power Consumption | <5.4W |
| Operating Conditions | -40ºC ~ +60ºC / Less than 95% RH |
| Storage Conditions | -40ºC ~ +60ºC |
| Ingress Protection | IP67 |
| Casing | Metal |
| Dimensions | 192.7 mm × 70.5 mm × 66.4 mm |
| Net Weight | 590g |
| Gross Weight | 780g |
