| Specifications: | |
| Model Number | SWITCH-8P |
| Hardware | |
| Included Power Adapter | Yes |
| PoE | Yes |
| Ethernet Port | 8 |
| Optical Port | 0 |
| Ethernet Port Speed | 10/100 Mbps |
| Ethernet Port Uplink Speed | 10/100 Mbps |
| Description of functions Slots | Port 1-8 8 x RJ-45 10/100 Mbps (PoE)
Port 9: 1 x RJ-45 10/100 Mbps (Uplink) |
| Power Supply | External Power Supply: 48-57 VDC, 2-1.68 A |
| Operating Temperature | –10 °C to +55 °C (+14°F to +131°F) |
| Operating Temperature | 5% - 95% (RH) |
| Power Consumption | Idling: 1.5 W
Full load: 96 W |
| Performance: | |
| Layer | Layer 2 |
| Management Type | No |
| Smart Managed Switch | No |
| Switching Capacity | 1.8 Gbps |
| Packet Forwarding Rate | 1.34 Mbps |
| Packet Buffer Size | 768 kbit |
| MAC Table Size | 2K |
| Communication Standard | IEEE 802.3; IEEE 802.3u; IEEE 802.3x |
| Feature | |
| PoE Protocol | IEEE802.3af; IEEE802.3at; Hi-PoE; IEEE802.3bt |
| PoE Power | 96W |
| Power Consumption Management | Yes |
| PoE Pin Assignment | 1,2,4,5(V+), 3,6,7,8 (V-) |
| ePoE | No |
| Long Distance PoE Transmission | Yes |
| PoE Watchdog | Yes |
| General | |
| Statics Protection | Air discharge: 8kV
Contact discharge: 6kV |
| Lightning Protection | Common mode: 4 kV
Differental mode: 2kV |
| Net Weight | 0.49 kg (1.08lb) |
| Gross Weight | 1.3 (2.87lb) |
| Product Dimensions | 190 mm × 100 mm × 30 mm (7.48" × 3.94" × 1.18") (L × W × H) |
| Casing Material | Iron |
| Installation | Desktop mount; wall mount |
| Certifications | CE; FCC |
