SPRO 8MP HDCVI Motorised Lens Bullet

SPRO 8MP HDCVI Motorised Lens Bullet
  Zoom
SPRO 8MP HDCVI Motorised Lens BulletSPRO 8MP HDCVI Motorised Lens BulletSPRO 8MP HDCVI Motorised Lens Bullet
SPRO 8MP HDCVI Motorised Lens BulletSPRO 8MP HDCVI Motorised Lens Bullet

Availability:



In stock, immediate despatch

Deep Base, White (BASE05-W)
Pole Bracket

Part Number:  DHQ80/ARW/60M
Camera Resolution:  8 Megapixels
Lens:  Motorised Lens
IR Distance:  Up to 60m IR distance
Protocol:  CVI
Style:  Bullet

The DHQ80/ARW/60M can capture 4k footage and offer up to 60m IR distance.

Due to the sensitivity of these cameras you may occasionally get some interference from the power supply. We recommend that you use either a 3amp ungrounded power supply.

Specifications:
Model Number DHQ80/ARW/60M
Image Sensor 1/2.7 inch CMOS
Effective Pixels 3840(H)×2160(V), 8MP
Electronic Shutter Speed 1/3s-1/100000s
Min. Illumination 0.03Lux/F1.7, 30IRE, 0Lux IR on
Max. IR LEDs Length Distance up to 60m
IR On/Off Control Auto/ Manual
IR LEDs 4
Lens
Lens Type Motorized lens
Mount Type φ14
Focal Length 2.7mm–13.5mm
Max Aperture F1.7
Angle of View H.: 105°–33° × V.: 56°–18°× D.: 126°–38°
Iris Type Fixed iris
Close Focus Distance 0.8m
DORI Distance Detect: 90-264 m
Observe: 36-106 m
Recognize: 18-53 m
Identify: 9-26 m
Pan / Tilt / Rotation
Pan/Tilt/Rotation Pan:0˚~360˚ / Tilt: 0° ~ 90° / Rotation: 0° ~ 360°
Video
Resolution 4K (3840 × 2160); 5M (2592 × 1944); 4M (2560 × 1440);
960H (960× 576/ 960 × 480)
Video Frame Rate CVI: 4K@15fps; 5M@20fps; 4M@25fps, CVBS: PAL/NTSC
Day/Night Auto switch by ICR
BLC Mode BLC / HLC / DWDR
WDR 120dB
White Balance Auto / Manual
Gain Control Auto / Manual
Noise Reduction 2D & 3D NR
Smart IR Yes
Electronic Defog Yes
Digital Zoom 4X
Mirror Off/On
Privacy Masking Off/On (8 Area, Rectangle)
Port
Audio Port N/A
Video Port Video output: HDCVI
General
Power Supply DC12V±30%
Power Consumption Max 11W (12V DC, IR on)
Operating Conditions -30°C ~ +60°C / Less than 90% RH
Strorage Conditions -30°C ~ +60°C / Less than 90% RH
Protection Grade IP67
Casing Aluminium
Dimensions 244mm × 90mm × 90mm (9.61"× 3.5"× 23.5")
Net Weight 0.42kg (0.93lb)
Gross Weight 0.53kg (1.17lb)
