POE Extender

POE Extender
  Zoom
 POE ExtenderPOE Extender

Availability:



In stock, immediate despatch

Part Number:  POEEXTENDER-01
IP Accessories:  POE Extender

Up to 100 meter transmission distance
Ethernet and PoE connection
Fully IEEE802.3af/IEEE802.3at compliant
Plug & Play. No configuration required
Support PoE power up to 15.4W
Full-rate network throughout the whole
extended distance
Dimensions: 11.5 (W) x 2.8 (H) x 8.5 (D)cm

Specifications:
Model Number POEEXTENDER-01
Compliance IEEE 802.3af, IEEE 802.3at, Support PoE power up to 15.4W
Processing types Store-and-forward Half-duplex back pressure;
IEEE802.3x full- duplex flow control .
Data Rate 10/100Mbps
Pin Definition 12/36 for power/45/78 for data
PoE Power Input 48V
PoE Power Output 48V
Network Standards IEEE802.3i 10BASE-T ;
IEEE802.3u 100BASE-TX
IEEE802.3x Flow Control;
IEEE 802.3af,
IEEE 802.3at Power over Ethernet
LED Display Yes
Operating Tem. -10 C to 50 C
Storage Tem. -20 C to -70 C
Operating Humidity 90% max relative humidity,non-condensing
Storage humidity 90% max relative humidity, non-condensing
Certification CE,FCC,RoHs
