| Specifications: | |
| Model Number | DHIPPTZ40/4XR |
| Image Sensor | 1/2.8" STARVIS™ CMOS |
| Pixel | 4MP |
| Max. Resolution | 2560 (H) x 1440 (V) |
| ROM | 4GB |
| RAM | 1GB |
| Electronic Shutter Speed | 1/1 s-1/30,000 s |
| Scanning System | Progressive |
| Min. Illuminations | Colour: 0.005 Lux @ F1.8 B/W: 0.005 Lux @ F1.8 0Lux (IR light on) |
| Illumination Distance | 15 m (49.21 ft) |
| Illuminator On/Off Control | Zoom Prio / Manual / Smart IR |
| Illuminator Number | 3 |
| Lens | |
| Focal Length | 2.8mm-12mm |
| Max. Aperture | F1.8 - F2.7 |
| Field of View | H: 31.6°–96.9° V: 17.8°–51.4° D: 36.4°–116.2° |
| Optical Zoom | 4x |
| Focus Control | Auto / Semi-Auto / Manual |
| Close Focus Distance | 0.2m - 0.5m (0.66ft - 1.64ft) |
| Iris Control | Auto |
| Dori Distance | Detect : 147.0m (482.28ft)
Observe: 58.8m (192.91ft)
Recognise: 29.4m (96.46ft)
Identify: 14.7 (48.23ft) |
| PTZ | |
| Pan / Tilt Range | Pan: 0°–355° / Tilt: 5°–90° |
| Manual Control Speed | Pan: 0.1°/s–70°/s / Tilt: 0.1°/s–30°/s |
| Preset Speed | Pan: 80°/s / Tilt: 40°/s |
| Presets | 300 |
| Tour | 8 (up to 32 presets per tour) |
| Speed Adjustment | Support |
| Power -off Memory | Support |
| Idle Motion | Preset / Tour |
| General Intelligence | |
| Video Trigger | Motion detection, Video tampering, Scene changing, Network disconnection, IP address conflict, Illegal Access, Storage anomaly |
| IVS | Object Abandoned / Missing |
| Artificial Intelligence | |
| People Counting | Count people entering and exiting the area (crossing people counting); count people staying in the area (in-area people counting); display and export reports by day, week and month. |
| Perimeter Protection | Tripwire and intrusion. Support alarm triggering by target types (human and vehicle). Support filtering false alarms caused by animals, rustling leaves, bright lights, etc. |
| SMD Plus | Support |
| Face Detection | Support |
| Video | |
| Compression | H.265; H.264BaselineProfile; H.264MainProfile; H.264HighProfile; MJPEG (Sub Stream); H.265+; H.264+ |
| Streaming Capability | 3 streams |
| Resolution | 4M (2560 x 1440); 3M (2048 x 1536); 1080P (1920 x 1080); 1.3M (1280 x 960); 720P (1280 x 720); D1 (704 x 576/704 × 480); CIF (352 x 288/352 × 240) |
| Frame Rate | Main stream: 4M/3M (1–25/30fps), 1080P/1.3M/720P (1–25/30fps) Sub stream 1: D1/CIF (1–25/30fps) Sub stream 2: 720P (1–25/30fps), D1/CIF (1–25/30fps) |
| Bit Rate Control | Variable Bit Rate / Constant Bit Rate |
| Bit Rate | H.264/H.265/MJPEG: 3 kbps–20480 kbps |
| Day / Night | Auto (ICR) / Colour / B/W |
| BLC | Support |
| WDR | 120 dB |
| HLC | Support |
| White Balance | Auto / Indoor / Outdoor / Track / Manual / Sodium lamp Natural light / Street lamp |
| Gain Control | Auto / Manual |
| Noise Reduction | 2D / 3D |
| Motion Detection | Support |
| Region of Interest (RoI) | Support |
| Electronic Image Stabilization | Support |
| Electronic Defog | Support |
| Digital Zoom | 16x |
| Flip | 0°/180° |
| Privacy Masking | Up to 24 areas, and up to 8 areas in the same view |
| Audio | |
| Compression | G.711a; G.711Mu; G.726; AAC; MPEG2-Layer2; G.722.1; G.729; G.723 |
| Network | |
| Ethernet | RJ-45 (10/100Base-T) |
| Protocol | IPv4; IPv6; HTTP; HTTPS; 802.1x; Qos; FTP; SMTP; UPnP; SNMPv1/v2c/v3(MIB-2); DNS; DDNS; NTP; RTSP; RTP; TCP; UDP; IGMP; ICMP; DHCP; PPPoE; ARP; RTCP |
| Interoperability | ONVIF Profile S&G&T; CGI |
| Streaming Method | Unicast / Multicast |
| User / Host | 20 |
| Storage | FTP: Micro SD card (256G); P2P |
| Browser | IE; Chrome; Firefox; Safari (No version restriction) |
| Management Software | DMSS |
| Mobile Phone | iOS / Android |
| Certification | |
| Certifications | CE: EN55032/EN55024/EN50130-4 FCC: Part15 subpartB, ANSI C63.4-2014 UL62368-1+CAN/CSA C22.2,No. 62368-1 |
| Port | |
| Audio Input | 1 (Line in; bare wire or bult in Mic) |
| Audio Output | 1 |
| Power | |
| Power Supply | DC12V/1.5A±15% / PoE (802.3af) |
| Power Consumption | 3W / 8.5W (IR on) |
| Environment | |
| Operating Temperature | -30°C to +60°C (-22°F to 140°F) |
| Operating Humidity | ≤95% |
| Protection | IK08; IP66; TVS 6000V lightning proof; surge protection |
| Structure | |
| Dimensions | Φ128.0 mm × 65.4 mm (5.04" × 2.57") |
| Net Weight | 0.485 kg (1.06 lb) |
| Gross Weight | 0.7 kg (1.54 lb) |
