| Specifications: | |
| Model Number | DHD50/ARW/60-M |
| Image Sensor | 1/2.7 inch CMOS |
| Max. Resolution | 2880 (H) × 1620 (V) |
| Pixel | 5 MP |
| Scanning System | Progressive |
| Electronic Shutter Speed | PAL: 1/25 s–1/100,000 s; NTSC: 1/30 s–1/100,000 s |
| S/N Ratio | >65 dB |
| Min. Illumination | 0.005 Lux/F1.6, 30IRE, 0 Lux IR on |
| Illumination Distance | 60 m (196.9 ft) |
| Illuminator On/Off Control | Auto/ Manual |
| Illuminator Number | 60 m (196.9 ft) |
| Illuminator On/Off Control | Auto; manual |
| Pan/Tilt/Rotation Range | Pan: 0°–360°; Tilt: 0°–78°; Rotation: 0°–360° |
| Lens | |
| Lens Type | Motorized vari-focal |
| Auto Focus | N/A |
| Mount Type | φ14 |
| Focal Lenght | 2.7 mm - 12 mm |
| Max. Aperture | F1.6 |
| Field of View | Diagonal: 39°–130° ; Horizontal: 34°–107° ; Vertical: 19°–55° |
| DORI Distance | 2.7mm
Detect: 69 m
Observe: 27.6 m
Recognize: 13.8 m
Identify: 6.9 m
12mm
Detect: 191.6 m
Observe: 76.64 m
Recognize: 38.32 m
Identify: 19.16 m |
| Video | |
| Frame Rate | CVI:
PAL: 5M@25 fps; 4M@25 fps; 1080P@25 fps
NTSC: 5M@25 fps; 4M@30 fps; 1080P@30 fps |
| Resolution | 5M (2880 × 1620); 4M (2560 × 1440); 1080p (1920 × 1080); 960H (960 × 576/960 × 480) |
| Day/Night | Auto switch by ICR |
| BLC | BLC/HLC/DWDR |
| WDR | DWDR |
| White Balance | Auto; manual |
| Gain Control | Auto; manual |
| Smart IR | Yes |
| Mirror | Off / On |
| Privacy Masking | Off/On (8 areas, rectangle) |
| Port | |
| Audio Input | One channel built-in-mic |
| Video Output | BNC |
| General | |
| Power Supply | DC 12V ±30% |
| Power Consumption | Max 6.6W (12V DC, IR on) |
| Operating Conditions | –30°C to +60°C (–22°F to +140°F); < 95% (non-condensation) |
| Storage Conditions | –30°C to +60°C (–22°F to +140°F); < 95% (non-condensation) |
| Ingress Protection | IP67 |
| Casing | Metal throughout the whole casing |
| Dimensions | φ122 mm × 104.8 mm (φ4.80" × 4.13") |
| Net Weight | 0.57 kg (1.26 lb) |
| Gross Weight | 0.72 kg (1.59 lb) |
