Part Number: DHD80/28RW/30-4-M
Brand: SPRO
Camera Resolution 8 Megapixels
Lens Fixed Lens
IR Distance Up to 30m IR distance
Protocol 4in1: CVI, TVI, AHD & CVBS
Built-in Mic. Yes
Ingress Protection IP67

Information
Specifications
Delivery

Upgrade security with the SPRO 8MP Fixed Lens Turret Camera.

This remarkable camera boasts an astounding 4K maximum resolution, ensuring that every detail is captured with breathtaking clarity.

Supporting multiple video formats, including CVI, CVBS, AHD and TVI makes integration into existing systems seamless.

With a built-in microphone that captures crystal-clear audio, it also has exceptional night vision and a maximum IR distance of 30 metres.

Key Features

Max. 4K resolution
CVI/CVBS/AHD/TVI switchable
2.8 mm fixed lens
Built-in Mic
Max. IR length 30 m, Smart IR
IP67, DC12V

Specifications:
Model Number	DHD80/28RW/30-4-M
Camera
Image Sensor	1 / 2.7 inch CMOS
Max. Resolution	3840 (H) x 2160 (V)
Pixel	8 MP
Scanning System	Progressive
Electronic Shutter Speed	PAL: 1/25 s–1/100, 000s; NTSC: 1/30 s–1/100, 000 s
S/N Ratio	> 65 dB
Min. Illumination	0.03 Lux/ F2.0, 30 IRE, 0 Lux IR on
Illumination Distance	30 m (98.4ft)
Illuminator On/Off Control	Auto; Manual
Illuminator Number	1 (IR light)
Pan / Tilt / Rotation Range	Pan: 0°–360°; Tilt: 0°–78°; Rotation: 0°–360°
Lens
Lens Type	Fixed lens
Mount Type	M12
Focal Length	2.8 mm
Max. Aperture	F2.0
Field of View	H:105° V:56° D:125°
Iris Type	Fixed
Close Focus Distance	1.0 m (3.3 ft);
DORI	Detect: 75m (246.1 ft) Observe: 30m (98.4 ft) Recognise: 15m (49.2 ft) Identify: 8m (26.2 ft)
Day / Night	Auto switch by ICR
BLC	BLC / HLC / DWDR
WDR	DWDR
White Balance	Auto / Manual
Gain Control	Auto / Manual
Noise Reduction	2D NR
Smart IR	Yes
Mirror	Off/ On
Privacy Masking	Off / On (8 area, rectangle)
Certifications
Certifications	CE (EN55032, EN55024, EN50130-4, EN62368-1) FCC (CFR 47 FCC Part 15 subpartB, ANSI C63.4-2014) UL (UL60950-1+CAN/CSA C22.2 No.60950-1)
Port
Video Output	Video output choices of CVI/TVI/AHD/CVBS by one BNC port
Audio Input	One channel built-in Mic
Power
Power Supply	12V ±30% DC
Power Consumption	Max 4.3 W (12V DC, IR on)
Environment
Operating Temperature	–40°C to +60°C (–40°F to 140°F); < 95% (non-condensation)
Storage Temperature	–40°C to +60°C (–40°F to 140°F); < 95% (non-condensation)
Protection Grade	IP67
Structure
Casing	Metal throughout the whole casing
Camera Dimensions	φ94.0 mm × 85.7 mm (φ3.70" × 3.37")
Net Weight	0.33 kg (0.73 lb)
Gross Weight	0.47 kg (1.04 lb)
