| Specifications: | |
| Model Number | DHIPD40/ARW/40-M-I |
| Image Sensor | 1/2.9” 4MP CMOS |
| Effective Pixels | 2688(H) x 1520(V) |
| ROM | 128 MB |
| RAM | 128 MB |
| Scanning System | Progressive |
| Electronic Shutter Speed | Auto/Manual 1/3 s–1/100,000 s |
| Min. Illumination | 0.008 lux@F1.5(Color,30IRE)
0.0008 lux@F1.5(B/W,30IRE)
0 lux (Illuminator on) |
| S/N Ratio | <56 dB |
| Illumination Distance | 40 m (131.23 ft) |
| Illuminator On/Off Control | Auto/Manual |
| Illuminator Number | 2 (IR LED) |
| S/N Ratio | >56dB |
| Lens | |
| Lens Type | Motorised vari-focal |
| Mount Type | φ14 |
| Focal Length | 2.7mm ~ 13.5mm |
| Max. Aperture | F1.5 |
| Angle of View | Horizonal: 104°–29° × Vertical: 54°–16° × Diagonal: 125°–34° |
| Iris Type | Fixed |
| Close Focus Distance | 0.8m |
| DORI Distance | Detect: 64-210m, Observe: 25.6-84m, Recognize: 12.8-42m, Identify: 6.4-21m |
| Pan / Tilt / Rotation | |
| Pan / Tilt / Rotation Range | Pan:0˚~360˚, Tilt:0˚~78˚, Rotation:0˚~360˚ |
| Intelligence | |
| IVS | Tripwire, Intrusion ( The two functions support the classification and accurate detection of vehicle and human ) |
| Smart Function | Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos. |
| Video | |
| Compression | H.265; H.264; H.264H; H.264B; MJPEG (Only supported by the
sub stream) |
| Smart Codec | Smart H.265+; Smart H.264+ |
| Video Frame Rate | Main stream: 2688x1520@(1-20fps)/2560x1440@(1-25/30 fps)
Sub stream: 704x576@(1-25fps)/704 x 480@(1-30fps)
*the values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity. |
| Stream Capability | 2 streams |
| Resolution | 2688 × 1520 (2688 × 1520); 2560 × 1440 (2560 × 1440);
2304 × 1296 (2304 × 1296); 1080p (1920 × 1080);
1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480);
VGA (640 × 480); CIF (352 × 288/352 × 240) |
| Bit Rate Control | CBR / VBR |
| Video Bit Rate | H.264: 32kbps-6144 kbps
H.265: 12kbps-6144 kbps |
| Day / Night | Auto (ICR); Colour; B/W |
| BLC | Yes |
| HLC | Yes |
| WDR | 120 db |
| White Balance | Auto; natural; street lamp; outdoor; manual; regional custom |
| Gain Control | Manual; Auto |
| Noise Reduction | 3D NR |
| Motion Detection | OFF/ON (4 areas, rectangular) |
| Region of Interest (RoI) | Yes (4 areas) |
| Smart Illumination | Yes |
| Image Rotation | 0°/90°/180°/270° (Support 90°/270° with 2688 × 1520 resolution
and lower) |
| Mirror | Yes |
| Privacy Masking | 4 areas |
| Audio | |
| Built-in MIC | Yes |
| Audio Compression | G.711a; G.711Mu; G.726; PCM |
| Alarm | |
| Alarm Event | No SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; motion detection; video tampering;
tripwire; intrusion; audio detection; voltage detection; defocus detection; SMD; security exception |
| Network | |
| Network Port | RJ-45 (10/100 Base-T) |
| SKD and API | Yes |
| Network Protocol | IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP;
FTP; SFTP; DHCP; DNS; DDNS; NTP; Multicast; ICMP; IGMP |
| Interoperability | ONVIF (Profile S/Profile T): CGI; P2P; Milestone |
| User / Host | 6 ( Total bandwidth: 36M ) |
| Storage | FTP; SFTP; Micro SD card (support max. 256 GB) |
| Browser | IE; Chrome; Firefox |
| Management Software | SPRO CSS |
| Mobile Client | iOS; Android |
| Cyber Security | Video encryption; Configuration encryption; Digest; WSSE; Account lockout; Security logs; IP/MAC filtering; Generation and importing of X.509 certification;
syslog; HTTPS; 802.1x; Trusted boot; Trusted execution; Trusted upgrade |
| Certification | |
| Certifications | CE-LVD:EN62368-1;
CE-EMC:Electromagnetic Compatibility Directive 2014/30/EU;
FCC: 47 CFR FCC Part 15, Subpart B |
| Power | |
| Power Supply | 12 VDC/PoE (802.3 af) |
| Power Consumption | Basic: 1.9 W (12 VDC); 2.8 W (PoE)
Max. (H.265+intelligence on +WDR +IR on): 6.1 W (12 VDC); 7.3 W (PoE) |
| Environment | |
| Operating Temperature | –30 °C to +60 °C (–22 °F to +140 °F) |
| Operating Humidity | ≤95% |
| Storage Temperature | –40 °C to +60 °C (–40°F to +140°F) |
| Protection | IP67 |
| Structure | |
| Casing Material | Metal |
| Product Dimensions | 108.3 mm × Φ122 mm (4.26" × Φ4.80") |
| Net Weight | 0.86 kg (1.90 lb) |
| Gross Weight | 0.69 kg (1.52 lb) |
